UC-CAN 16-bit D/A converter with galvanic isolation – 2 channels

Our UC-CAN modules are stand-alone modules and have a USB and CAN interface with open CAN protocol. With the help of our automatic CAN RX/TX mode, CAN packets can be received or sent independently within a network. The UC-CAN-DA2-16_ISO module has 2 analog outputs with 16 bit resolution each.

You can also call the latest from our company an analog measuring box. Numerous industrial applications where analog measured values are to be output, whether in the voltage or current range, can be accomplished with this new CAN D/A module. Whether +-5V or +-10V or currents in the 0-20mA range are output with high precision thanks to the 16-bit D/A converter used. The new analog USB/CAN measuring box has two D/A channels that are completely independent of each other. This also results in galvanic isolation from each other and, of course, from the digital ground.

Outputting voltages with a longer cable path is no problem for the module. This is ensured by the two voltage outputs in conjunction with the two sense inputs. This means that 4 lines must be laid to the object, but the voltage drop is automatically compensated for by the D/A converter with longer lines thanks to the sense lines.
